PRODUCT DESCRIPTION

AZS Ramming Mass

Description

Fused Cast AZS Ramming Mass is a high-performance, monolithic refractory material expertly formulated from crushed high-purity fused cast AZS aggregates, premium synthetic powders, and specialized high-temperature binders. Engineered with a finely optimized particle size distribution, this chemically bonded monolithic material is designed to create a seamless, impenetrable, and highly densified refractory lining upon ramming and thermal curing. It serves as the ultimate protective monolithic barrier or leveling layer in glass melting furnaces, particularly deployed beneath AZS paver blocks to prevent bottom metal drilling and joint glass leakage.

Advantages

l  Exceptional Glass Corrosion Resistance
Inheriting the premium properties of the baddeleyite and corundum phases from fused cast AZS aggregates, it forms a chemically inert matrix engineered to effectively withstand corrosion from molten glass and corrosive batch vapors.

l  Monolithic Leak-Proof Barrier

Upon heating, the material sinters into a monolithic, joint-free barrier. This seamless lining completely seals the furnace bottom, eliminating joint erosion while effectively blocking downward glass infiltration and upward drilling erosion.

l  High Structural Density & Low Apparent Porosity
The carefully graded particle matrix ensures optimized packing density upon compaction, effectively preventing the penetration of high-fluidity molten glass and aggressive tramp metals.

l  Superb Thermal Shock & Creep Resistance
Maintains excellent volume stability and high-temperature mechanical strength, effectively preventing shrinkage, thermal cracking, or structural degradation under extreme and continuous thermal stress.

l  Easy Application & Long Storage Life
Formulated for optimal plasticity, it allows for effortless ramming and compaction, molding seamlessly around intricate furnace geometries like thermocouple blocks. Meanwhile, its advanced chemical bonding ensures a prolonged, stable shelf life under proper storage conditions.

Applications

AZS Ramming Mass is strategically deployed to reinforce high-wear, high-risk zones across float glass, container glass, special borosilicate, and technical electronic glass furnaces:

l  Furnace Bottom Safety Sub-Layers
Applied directly underneath AZS bottom paving blocks to act as a crucial secondary monolithic barrier against glass infiltration.

l  Refractory Joint & Gap Sealing
Used to fill and pack expansion joints, construction gaps, and crevices between large fused cast AZS blocks to prevent localized fluid erosion.

l  Thermocouple Blocks & Bubbler Surroundings
Injected or rammed around bottom bubbler pipes, electrodes, and thermocouple blocks where precise molding, tight sealing, and high chemical resistance are required.

l  Doghouse Charging Zone Linings
Deployed as a robust backup lining in charging areas to endure severe temperature fluctuations and chemical vapor attack from batch raw materials.

l  Melting Basin Repair & Hot Maintenance
An indispensable monolithic solution for fast-track partial relining, urgent patchwork, or preventative hot maintenance of eroded refractory sub-structures.

   TECHNIQUE DATA

Technical Data
